PRODUCT OVERVIEW
Series information
Cartridge kits identified by the V / VQ pump family and section configuration. Provide the full pump code and the kit position so the required service assembly can be reviewed.
TECHNICAL SELECTION
Specifications & configuration
Do not select by appearance alone. Similar cartridge bodies can represent different displacement codes or rotations, and multi-section pumps require position-specific identification.
Identify the parent pump and the section being serviced before comparing cartridge references.
| Parameter | What it tells you |
|---|---|
| Parent pump | A family name alone does not identify the required kit. |
| Pumping section | Identify the section in a double or triple pump. |
| Kit configuration | Confirm the cartridge code, rotation and included parts. |
| Service history | Describe why the kit is being replaced for technical review. |
ENGINEERING DOCUMENTATION
Technical documents
- V cartridge kits ↗PDF pages 22–22 · printed pages 38
- VQ cartridge kits ↗PDF pages 29–29 · printed pages 52
PDF and printed page numbers may differ.
Confirm the applicable revision, dimensions and operating limits for your complete model.
Request a drawing or current revision ›PROCUREMENT SUPPORT
Prepare your inquiry
- V or VQ family and complete code
- Section position in the pump
- Displacement code and rotation
- Photos of the existing kit and mating components
Include quantity, destination, requested delivery date and required documents. For a replacement, add nameplate and installation photos.
Inquire about this series ›
